Tariff-Free Sprayer Valves
From Factory Floor to Field: A Complete Guide to Installing TIR Texas-Made Solenoid Valves.
When a sprayer system goes down, every idle hour shows up on your bottom line. That’s why farmers, OEM engineers, and maintenance crews across North America rely on Texas Industrial Remcor (TIR). Every solenoid valve, pressure regulator, and control system we ship is:
- Manufactured start-to-finish in Little River-Academy, Texas — no off-shoring, ever.
- Tariff-free, so you’re never blindsided by surprise import duties.
- In stock and ready to leave the dock the same day (order by 3 p.m. CT) or first thing the next morning.
1. Understanding Sprayer Valves — and the Texas Advantage
Sprayer valves regulate fluid flow in everything from 120-foot boom sprayers to high-pressure industrial wash systems. TIR’s line includes:
| Valve Type | Typical Uses | Texas Industrial Remcor Edge |
|---|---|---|
| Solenoid (normally open/closed) | Precision pesticide, herbicide, coolant, or chemical dosing | Fast-acting coils wound in-house for tighter QC and extended coil life |
| Ball / Manual | General shut-off or throttling where simplicity is key | CNC-machined brass & stainless bodies that outlast cast imports |
| Check & Relief | Back-flow prevention, over-pressure relief | Viton® and EPDM seals molded in Texas for chemical compatibility |
Because we build in Texas, there’s no tariff mark-up, yet every valve is ISO-calibrated and pressure-tested before it reaches your loading dock.
2. Preparing for Installation: Tools, Materials, and a Two-Day Turnaround
Before you turn the first wrench, make sure yesterday’s parts order is on your bench — and with TIR’s next-day shipping, it will be. Gather:
- Wrenches, screwdrivers, pliers, and the correct-size fittings (all shipped with the valve if requested).
- Teflon® tape or PTFE thread sealant — we apply a light factory coating, but a fresh wrap ensures leak-free joints.
- Replacement seals/O-rings (included in TIR service kits).
- Level and measuring tape for perfect boom alignment.
- Safety gear (gloves, goggles), plus a clean, well-lit workspace.
Pro-tip: tape a copy of the TIR spec sheet to your tool cart. It lists torque settings and coil amperage draw, so you won’t need to guess.
3. Step-by-Step Installation
- Kill the Pressure
Shut off pumps, relieve line pressure, and lock out the power source. - Remove the Old Valve
Note orientation and wiring. Snap a phone pic for reference. - Clean & Inspect
Scrape old sealant, flush debris, and verify threads are undamaged. - Dry-Fit the New TIR Valve
Every valve ships with ports pre-plugged to keep grit out during transit. - Seal & Secure
Wrap male threads with PTFE tape (two full turns), then hand-tighten and finish with a wrench. Do not overtighten — our brass and stainless threads are precision-cut; crushing them defeats the purpose. - Wire the Coil
Match voltage (12 V, 24 V, 110 V, etc.). TIR coils are polarity-agnostic, but proper crimping and heat-shrink ensure longevity. - Verify Orientation & Flow Direction
The arrow on every TIR valve body is laser-etched in-house for life-long readability. - Slowly Re-Pressurize
Watch for weeps or drips; tighten a quarter-turn if needed. - Cycle-Test
Energize the coil or open the manual handle ten times to seat seals and purge air. - Document
Log the install date and part number. TIR serializes every unit, so future spares are a phone call away.
4. Installation Pitfalls to Dodge
| Mistake | What Happens | How TIR Helps You Avoid It |
|---|---|---|
| Skipping the manual | Mis-wiring, wrong torque | QR code on every box links to the PDF in seconds |
| Overtightening | Cracked housings | Machined flats show you exactly where to stop |
| No thread sealant | Micro-leaks | PTFE included in our Rapid-Install™ kits |
| Wrong coil voltage | Burnout in minutes | Color-coded coil leads = foolproof hookup |
| Skipping a leak test | Hidden drips ruin crops | Built-in LED coil indicator confirms actuation |
5. Maintenance That Pays for Itself
Because our valves are made in Texas, not just “assembled” here, spare parts are on the shelf — not stuck on the water for six weeks.
- Monthly: Visually inspect coils for discoloration, check harness strain relief.
- Seasonally: Swap O-rings (5-minute job with TIR seal kits).
- Annually: Bench-test coil resistance; readings are laser-etched on each coil cap for comparison.
Keep a simple spreadsheet (download one at sprayervalves.com/tools) and you’ll catch issues before they cost you acres or downtime.
6. Texas Industrial Remcor Product Highlights
- Solenoid Valves — ¼” to 1″ NPT, up to 350 psi, nylon, brass, or 316 SS, all wound with Class H copper wire.
- Pressure Regulators — maintain ±2 psi accuracy; tamper-proof caps available.
- Control Systems — CAN-Bus and ISOBUS ready; custom harnessing built in-house.
- Custom Manifolds — 3-D printed prototypes in 72 hrs, CNC aluminum or Delrin® production runs in two weeks.
All qualify for Zero-Tariff, Same/Next-Day Ship service from central Texas — meaning ground freight hits most U.S. locations in three business days or less.
7. Frequently Asked Questions
Q: Can I really install a solenoid valve myself?
A: Yes. Follow the steps above, use the torque specs in the box, and you’re good to go. Still unsure? Our tech desk (254-982-4236).
Q: Do your U.S.-made valves cost more?
A: Factor in zero tariffs, shorter transit, and longer service life and you’ll find the total cost of ownership is lower than most imports.
8. Ready to Order? Here’s How Fast It Happens
- Quote in 30 minutes — email specs to sales@sprayervalves.com.
- PO by 3 p.m. CT — ships today.
- Back in the field tomorrow for most of the Midwest and South; two days to the coasts.
Final Word
Installing sprayer valves doesn’t have to be daunting when you start with Texas-made, tariff-free components that arrive the day after you order. Follow the guide above and you’ll enjoy leak-free performance, longer valve life, and the peace of mind that only comes from partnering with a company that signs every shipment with a handshake’s worth of Texas pride.
Questions? Call (254) 982-4236, jump on sprayervalves.com, or connect with us on LinkedIn, Facebook, X, and Instagram for live installation tips, and product updates.
